High measurement accuracy. Integrated 24-bit ADC up to 0.1 leve
Integrated TRMS does not require an external rectifier device for AC measurement
The IC is highly integrated resulting in a single chip solution
Internal integrated DSP unit supports digital calibration
High measurement accuracy. Integrated 24-bit ADC up to 0.1 leve
Integrated TRMS does not require an external rectifier device for AC measurement
The IC is highly integrated resulting in a single chip solution
Internal integrated DSP unit supports digital calibration
Measurement accuracy: up to 0.1 level
Display range: 3.5, 4, 4.5 digit
Conversion rate: 3-4 times per second
Display mode: LCD/LED driver
AC bandwidth: Maximum support is 400Hz
Alarm output supports 2 independent alarm output and flexible configuration
Operating voltage range: 2.4~3.6V
Calibration method: Digital calibration. Internal memory can be used
